Final Submission

DA submission, SOEE & sketchup model - https://www.dropbox.com/sh/tgy5l7ll40fxzn7/4y4S6AuLNr

Site Analysis

General Info

The location of the site is situated on 5 Wyargine St, Mosman. The site is within 60m of the coastline, has a floor ratio of 1:50 (Mosman LEP) and comes to a total of 713m square. It has a minimal tree density with the maximum residential height of 8.5m.Planning

Planning Controls

Height
Maximum height for any structure: 8.5m
Maximum wall height 7.2m above the existing ground level

FLOOR SPACE
Floor space ratio: 1:50
Total area 713 sqm
Maximum floor space is 335sqm

SET BACK
Appropriate to neightors
1 story: 900mm, 2 story:1.5m
From any Sewage : 2m

assignment 01

Sketchup model and PDF file

https://www.dropbox.com/sh/bcgi8wve6wwidmx/65MUu8QlvR

Animation Video

Week 04

Research for BMW Welt

Plans

Level 0

Level 1

Level 2

Level 3

Level 4

Roof plan

Sections

Exterior

Interior

Analysis

RED: Private space

YELLOW: Semi-private space

BLUE: Public space

week 3 shapes

Week 02 - paper folding

First model:

The first model I have created is not based on any actual architecture by Coop Himmelblau but the general style and concept of Coop Himmelblau's architectures. Most of the Coop Himmelblau's architectures are formed by some random shape and we can always see some combinations of curves and straight lines in a same architecture and these ideas make me create such model.

Martin Luther Church:

Another model I have create is based on the Martin Luther Church and we can see that how beautiful the curved shape the building is.

UFA Cinema Center:

For the third model, we are allowed to create in anyway we want but not only folding. Therefore, I tried to create a more complex architecture - the UFA cinema center. Although, we can use more than one paper, it is still quite hard to create such building and actually all of the Coop Himmelblau's architectures are quite hard to create by just some paper as their buildings have really complex shape. I think I have already done quite well this time

Week 01 Design Influence: Coop Himmelblau

Coop Himmelblau:

COOP HIMMELB(L)AU was founded by Wolf D. Prix, Helmut Swiczinsky, and Michael Holzer in Vienna, Austria, in 1968, and is active in architecture, urban planning, design, and art. In 1988, a second studio was opened in Los Angeles, USA. Further project offices are located in Frankfurt, Germany and Paris, France. COOP HIMMELB(L)AU employs currently 150 team members from nineteen nations.

(source: http://www.coop-himmelblau.at/studio/profile/ )



Groninger Museum, in the Netherlands

Gasometer in Vienna
